6m Chinese Asphalt Concrete Paver RP601
6m Chinese Asphalt Concrete Paver RP601paver is the first set of full hydraulic medium 3 series wheel asphalt concrete paver launched by Xugong Group; the whole machine adopts full hydraulic drive and electro-hydraulic automatic control, whose technology is advanced and performance is reliable; it i......
Send Inquiry
Product Description
6m Chinese Asphalt Concrete Paver RP601
paver is the first set of full hydraulic medium 3 series wheel asphalt concrete paver launched by Xugong Group; the whole machine adopts full hydraulic drive and electro-hydraulic automatic control, whose technology is advanced and performance is reliable; it is widely applied to paving construction in a wide range, including side pavement, bike path, urban roads and small roads. Its paving width ranges from 2.5m to 6.0m which is stepless adjustable, so it is especially suitable for maintenance construction of grade highways.
| Number | Item | Unit | Performance Parameters |
| 1 | Basic paving width | m | 2.5~4.75 |
| 2 | Maximum paving width | m | 6.0 |
| 3 | Maximum paving thickness | mm | 200 |
| 4 | Working speed | m/min | 0~15 |
| 5 | Running speed | km/h | 0~15 |
| 6 | Theoretical productivity | t/h | 400 |
| 7 | Bucket capacity | t | 13 |
| 8 | Gradeability | % | 20 |
| 9 | Flatness | mm/3m | 2 |
| 10 | Camber adjustable range | % | -1~3 |
| 11 | Power of diesel engine | kW | 103 |
| 12 | Speed of diesel engine | rpm | 2200 |
| 13 | Material conveying speed | m/min | 0~28 |
| 14 | Material distributing speed | r/min | 0~75 |
| 15 | Vibration speed | r/min | 0~1500 |
| 16 | Vibration stroke | mm | 4 |
| 17 | Outside dimensions | mm | 6590×2600×3942 |
| 18 | Transportation dimension | mm | 6435×2600×3281 |
| 19 | Overall weight | t | 19 |
| 20 | The maximum working status quality | t | 20 |
| 21 | Volume of diesel tank | L | 180 |
| 22 | Volume of hydraulic oil tank | L | 200 |
